An excellent tool for novice coders, Arduino IDE, is a free Java-based open-source tool that allows you to write and upload code to a working environment. The program works with all Arduino-based boards and microcontrollers. Follow the simple steps to download Arduino IDE for free and start writing code for your boards today. Permanent Redirect. Download Arduino Ide For Mac Os Free. Follow these steps to install the Arduino software on your Mac: This instructable helps you to download Arduino Software (Arduino IDE) for Windows, Linux, Mac OS. Following steps helps you in downloading the Arduino Software. Step1: Type Arduino in Google. Step2: Select Download tab in Arduino Website.
Jan 22, 2019 By Team YoungWonks *
How do you program an Arduino using a Mac? This blog will tell how. But before we get into that, let’s take a look at what is an Arduino?
What is Arduino?
An Arduino is basically a single board microcontroller that is used for building digital devices and interactive objects that can sense and control objects in the physical and digital world. These Arduino boards are available both in preassembled form or as do-it-yourself (DIY) kits. Arduino board designs use a variety of microprocessors and controllers. The boards come fitted with sets of digital and analog input/output (I/O) pins that can be interfaced to several expansion boards or breadboards (shields) and other circuits.
One of the biggest advantages that Arduino boards have over Raspberry Pi is the fact that they can read sensitive values from sensors and Arduino boards have analog input and output and not digital input output which is the case with Raspberry Pi. This is why in some instances - especially where exact values are needed - it is a more apt choice. Say, if you want to make a device that automatically waters your plants. Now to do this, you have to measure the exact soil moisture, so an Arduino is a better bet because it can read analog values as opposed to the Raspberry Pi which will need another chip to read analog values.
Arduino has low maintenance and doesn’t get disrupted by power outages. But image processing needs can be done better with Raspberry Pi and Pi camera.
In this blog, we shall look at how we can program an Arduino board using a Mac OS. Here’s the step-by-step process to program an Arduino board with a Mac:
Downloading and installing Arduino on a Mac
Step 1: Get all the needed equipment in place. This means having with you the Arduino Uno board and the USB data cable that will help you connect the board to your Mac.
You’ll also need a breadboard, jumper cables(M-M), an LED and a resistor (with a resistance of say, 330 Ohms).
Step 2: Then start by connecting the narrow end of the USB data cable to your Arduino board as shown below.
Step 3: Then connect the other end of the USB data cable to your Mac. At this stage, your Mac and the Arduino board have been connected to each other using the USB cable. Refer to the pic below.
Step 4: Now go on to download the Arduino IDE on your Mac. To do this, open Safari on your Mac and just go to the website www.arduino.cc. Once you have opened the website, go to the software section and click on downloads from the dropdown menu. Now select the Mac OS X version, hit download and wait for the download to finish. Once it downloads, one can run the Installer in the next step.
Step 5: To install the IDE, we need to run the file that we just downloaded. Click on Agree and continue with the default settings for the rest of the installation. Once the installation is done, click on the close button to finish the installation.
Now that we have downloaded and installed the Arduino IDE on our Mac, we can carry out a number of tasks using the Arduino IDE. This includes getting the board to say, “Hello World”, running the counter program and lighting an LED - all using the Arduino.
Saying “Hello World”
Let’s look at what goes into writing our first program, the “Hello World” program. Let’s open the Arduino IDE that we have installed on the Mac. Make sure you check the board name under the Tools option as Arduino Uno. Also make sure that the communication port is selected as COM3. Now to see the information sent by our Arduino, we have to open the serial monitor we see on the right.
In the program, we start by putting Serial.begin 9600 in the void setup function which is the one-time setup required for exchanging information over the serial port from the Arduino to the computer. 9600 here is called the baud rate. It is the rate at which the Arduino can send symbols or characters to the computer.
In the void loop function, we use a very simple serial.print to show data on the serial monitor.
You can first save it and then upload the design onto the Arduino. You’ll then see that the words “Hello World!” are being sent by the Arduino to the computer and we can see the words on the serial monitor. You’ll see that the words “Hello” and “World” are appearing next to each other. However, if we use a n in our print command, we will see the two words printed one below the other.
Running the Counter Program
Let’s take a look at the next program. We will design a simple counter by opening the Arduino IDE and the serial monitor. Let’s start by defining the counter variable. Here we say int <space> counter equals one and add a semicolon at the end. This initializes the value of the counter to 1 at the beginning. Now just like in the previous program, we initialize the serial connection.
In the loop, we print the counter value and we also increase the value of the count by one. Here, we use the printIn function to automatically add a new line after having printed the value of the counter. Now this would be too fast and for us to understand what’s happening in the output, we add a delay and the argument is in milliseconds. So for a one second delay, we provide an argument of thousand to the delay function. Finally, increase the value of counter by one using the counter++ statement. Once we save and upload this design onto the Arduino, we will be able to see that a counter variable is constantly being increased in value and this value is being communicated to the computer over the serial connection.
Lighting an LED
Lighting the inbuilt LED on the Arduino
Now the next program we will be working on is blinking the Arduino’s inbuilt LED. You can see that right next to pin number 13 among the digital pins, there’s an LED which is orange in colour. We will learn how to make it blink once every second. And just like we do with the Raspberry Pi, we will start by initializing the pin to be an output so we can control its values. Here we say pinMode and we say 13 which is the pin for the inbuilt LED and we set it as an output so that we can send values of high or low. We then begin our loop function by setting value of the 13 pin to 1 (or high). We do this by using the DigitalWrite function. We then add a delay of one second and then we set the value of the 13 pin as low. Don’t forget to add a delay after turning it low. Now when you run the code, you should be able to see the light next to the pin number 13 blink.
Writing the program to blink an LED on the breadboard
Here we will see how one can write the program that allows the Arduino to make an LED on the breadboard blink once every one second. Just like in the previous case, we will set values and this time, we will choose pin number 12 and we will set it as an output. So we type the pinMode, 12, output. In the void loop, we use the serial to communicate messages from the Arduino to the computer. We use the DigitalWrite function to turn the pin on or set it to high. Then we add the delay of one second. In the same fashion, we will turn the pin off by using the DigitalWrite function. Similarly, we can add a message and a delay so that we see the output very clearly.
Next you can save and upload this. Go to your Arduino, make sure you have the serial monitor open so you can see the output. Now this code seems to work as it prints LED high and LED low every one second. At this stage, we need to make an LED circuit on the breadboard and connect it to the Arduino to see the actual result.
Making connections to blink an LED on the breadboard
Now we will explore the connections to be made on the breadboard so as to make an LED blink from the Arduino.
Here’s how you make connections to blink an LED on the breadboard using an Arduino:
Just like with Raspberry Pi, we set up the LED first. We place the LED on the breadboard across the middle separation.
Then we add a resistor (say with a resistance in the range of 220 to 600 ohms). We place one end of the resistor on the same line as the LED.
Now we connect the resistor’s other end to the railing for the Ground.
We use a wire to connect it to the Ground pin on the Arduino.
The closeup of the Arduino after the connections have been made will look like this.
We then connect the other end of the LED to the pin number 12 which we are programming for.
The closeup of the breadboard after the connections have been made will look like this.
Since the program is already on the Arduino, we should immediately be able to see the light blink.
Here's a video explaining in entirety how to program an Arduino using a Mac:
*Contributors: Written by Vidya Prabhu; Lead image by: Leonel Cruz
So, I have Arduino Nano CH340x working on Mac OS (Mojave), Ubuntu 18.04, Elementary Linux (forget version) and openSuSE Leap 42.3 Malachite. It was not at all necessary to install drivers or make them on the Linux machines - but I did install them for the Mac. Open terminal and type: ls /dev/tty. Note the port number listed for /dev/ttyUSB. or /dev/ttyACM.The port number is represented with. here. Use the listed port. Free download Arduino Create Agent Arduino Create Agent for Mac OS X. The Arduino Create Agent is an open source single binary that reads from a configuration file. Open-source electronic prototyping platform enabling users to create interactive electronic objects. Go to the Arduino download page and download the latest version of the Arduino software for Mac.; When the download is finished, un-zip it and open up the Arduino folder to confirm that yes, there are indeed some files and sub-folders inside. Jun 27, 2012 Download Arduino Manager for macOS 10.13 or later and enjoy it on your Mac.
≡ PagesFavoritedFavorite14Introduction
This tutorial will walk you through downloading, installing, and testing the Arduino software (also known as the Arduino IDE - short for Integrated Development Environment). Before you jump to the page for your operating system, make sure you've got all the right equipment.
Required Materials
- A computer (Windows, Mac, or Linux)
- An Arduino-compatible microcontroller (anything from this guide should work)
- A USB A-to-B cable, or another appropriate way to connect your Arduino-compatible microcontroller to your computer (check out this USB buying guide if you're not sure which cable to get).
Suggested Reading
If you're new to Arduino in general, you want to check out this tutorial to familiarize yourself with everyone's favorite microcontroller platform.
What is an Arduino?
How to Install CH340 Drivers
If you're ready to get started, click on the link in the column on the left that matches up with your operating system, or you can jump to your operating system here.
Windows
This page will show you how to install and test the Arduino software with a Windows operating system (Windows 8, Windows 7, Vista, and XP).
- Go to the Arduino download page and download the latest version of the Arduino software for Windows.
- When the download is finished, un-zip it and open up the Arduino folder to confirm that yes, there are indeed some files and sub-folders inside. The file structure is important so don't be moving any files around unless you really know what you're doing.
- Power up your Arduino by connecting your Arduino board to your computer with a USB cable (or FTDI connector if you're using an Arduino pro). You should see the an LED labed 'ON' light up. (this diagram shows the placement of the power LED on the UNO).
Arduino Ide Download Mac
Drivers for Arduino Uno on Windows
Installing the Drivers for the Arduino Uno (from Arduino.cc)
- Plug in your board and wait for Windows to begin it's driver installation process
- After a few moments, the process will fail, despite its best efforts
- Click on the Start Menu, and open up the Control Panel
- While in the Control Panel, navigate to System and Security. Next, click on System
- Once the System window is up, open the Device Manager
- Look under Ports (COM & LPT). You should see an open port named 'Arduino UNO (COMxx)'. If there is no COM & LPT section, look under 'Other Devices' for 'Unknown Device'
- Right click on the 'Arduino UNO (COMxx)' or 'Unknown Device' port and choose the 'Update Driver Software' option
- Next, choose the 'Browse my computer for Driver software' option
- Finally, navigate to and select the Uno's driver file, named 'ArduinoUNO.inf', located in the 'Drivers' folder of the Arduino Software download (not the 'FTDI USB Drivers' sub-directory). If you cannot see the .inf file, it is probably just hidden. You can select the 'drivers' folder with the 'search sub-folders' option selected instead.
- Windows will finish up the driver installation from there
For earlier versions of the Arduino boards (e.g. Arduino Duemilanove, Nano, or Diecimila) check out this page for specific directions.
Drivers for RedBoard on Windows
If you are using a RedBoard programmed for Arduino, please go to How to Install FTDI Drivers, for specific instructions on how to install the drivers.
USB Serial Driver Quick Install
Launch and Blink!
After following the appropriate steps for your software install, we are now ready to test your first program with your Arduino board!
- Launch the Arduino application
- If you disconnected your board, plug it back in
- Open the Blink example sketch by going to: File > Examples > 1.Basics > Blink
- Select the type of Arduino board you're using: Tools > Board > your board type
- Select the serial/COM port that your Arduino is attached to: Tools > Port > COMxx
- If you're not sure which serial device is your Arduino, take a look at the available ports, then unplug your Arduino and look again. The one that disappeared is your Arduino.
- With your Arduino board connected, and the Blink sketch open, press the 'Upload' button
- After a second, you should see some LEDs flashing on your Arduino, followed by the message 'Done Uploading' in the status bar of the Blink sketch.
- If everything worked, the onboard LED on your Arduino should now be blinking! You just programmed your first Arduino!
Troubleshooting
This guide from Arduino has some more details and troubleshooting tips if you get stuck.
Mac
This page will show you how to install and test the Arduino software on a Mac computer running OSX.
- Go to the Arduino download page and download the latest version of the Arduino software for Mac.
- When the download is finished, un-zip it and open up the Arduino folder to confirm that yes, there are indeed some files and sub-folders inside. The file structure is important so don't be moving any files around unless you really know what you're doing.
- Power up your Arduino by connecting your Arduino board to your computer with a USB cable (or FTDI connector if you're using an Arduino pro). You should see the an LED labed 'ON' light up. (this diagram shows the placement of the power LED on the UNO).
- Move the Arduino application into your Applications folder.
FTDI Drivers
If you have an UNO, Mega2560, or Redboard, you shouldn't need this step, so skip it!
- For other boards, you will need to install drivers for the FTDI chip on your Arduino.
- Go to the FTDI website and download the latest version of the drivers.
- Once you're done downloading, double click the package and follow the instructions from the installer.
- Restart your computer after installing the drivers.
Launch and Blink!
After following the appropriate steps for your software install, we are now ready to test your first program with your Arduino board!
- Launch the Arduino application
- If you disconnected your board, plug it back in
- Open the Blink example sketch by going to: File > Examples > 1.Basics > Blink
- Select the type of Arduino board you're using: Tools > Board > your board type
Arduino Ide Download Mac
- Select the serial port that your Arduino is attached to: Tools > Port > xxxxxx (it'll probably look something like '/dev/tty.usbmodemfd131' or '/dev/tty.usbserial-131' but probably with a different number)
- If you're not sure which serial device is your Arduino, take a look at the available ports, then unplug your Arduino and look again. The one that disappeared is your Arduino.
- With your Arduino board connected and the Blink sketch open, press the 'Upload' button
- After a second, you should see some LEDs flashing on your Arduino, followed by the message 'Done Uploading' in the status bar of the Blink sketch.
- If everything worked, the onboard LED on your Arduino should now be blinking! You just programmed your first Arduino!
Troubleshooting
If you're having problems, check out this troubleshooting guide from Arduino.
Linux
If you are a Linux user, you probably know that there are many different distribution 'flavors' of Linux out there. Unsurprisingly, installing Arduino is slightly different for many of these distributions. Luckily, the Arduino community has done an excellent job of providing instructions for most of the popular versions. Click on the link below that covers your flavor of Linux:
If the above directions did not work for you, or you don't see your distribution, try this catch-all guide.
You can go to the download page and download the latest version of Arduino for Linux (there are 32-bit and 64-bit versions available) when your system is properly set up.
Launch and Blink!
After following the appropriate steps for your software install, we are now ready to test your first program with your Arduino board!
- Launch the Arduino application
- If you disconnected your board, plug it back in
- Open the Blink example sketch by going to: File > Examples > 1.Basics > Blink
- Select the type of Arduino board you're using: Tools > Board > your board type
- Select the serial port that your Arduino is attached to: Tools > Port > xxxxxx (it'll probably look something like '/dev/tty.usbmodemfd131' or '/dev/tty.usbserial-131' but probably with a different number)
- If you're not sure which serial device is your Arduino, take a look at the available ports, then unplug your Arduino and look again. The one that disappeared is your Arduino.
- With your Arduino board connected and the Blink sketch open, press the 'Upload' button
- After a second, you should see some LEDs flashing on your Arduino, followed by the message 'Done Uploading' in the status bar of the Blink sketch.
- If everything worked, the onboard LED on your Arduino should now be blinking! You just programmed your first Arduino!
Troubleshooting
The Arduino Playground Linux section is a great resource for figuring out any problems with your Arduino installation.
Board Add-Ons with Arduino Board Manager
With Arduino v1.6.4+, a new boards manager feature makes it easy to add third-party boards (like the SparkFun Redboard, Digital Sandbox, and RedBot) to the Arduino IDE.
To start, highlight and copy (CTRL + C / CMD + C) the text below for the boards manager URL. You'll need this to configure Arduino.
Open up Arduino:
- Configure the Boards Manager
- For Windows and Linux, head to File>Preferences>Additional Boards Manager URLs and paste (CTRL + V / CMD + V) the link
- For Macs, head to Arduino>Preferences>Additional Boards Manager URLs and paste (CTRL + V / CMD + V) the link
- Click on Tools>Board>Boards Manager...
- Select the Type as 'Contributed' from the drop down menu.
- Click on the SparkFun AVR Boards and then click Install
That's it! Boards are all installed. This also gives you access to all of our library files as well through the built-in Library Manager tool in Arduino. Looking for more information about adding other custom boards? Check out the the following tutorial to install other Arduino cores.
Installing Board Definitions in the Arduino IDE
Resources and Going Further
Now that you've got the Arduino software installed on your system and tested it with your Arduino board successfully, you're ready for your next steps into the world of embedded electronics. If you want to learn about some of the concepts that will help you build your projects, check out some of the following tutorials:
